General characteristics of sliding systems:

  • Space ergonomics, functionality, and uninterrupted views.
  • A wide range of typologies, overlapping systems & tracks.
  • Narrow overlaps & flat minimal-design tracks.
  • Large openings offering improved thermal insulation, security & silent operation.
  • For high-demand spaces, lift-and-slide mechanisms.
  • Roto-Hautaus (rollers with load resistance up to 400 kg per sash).
  • Special sealing gaskets & extra Elvial I² thermal insulation zone.

ABUNDANT NATURAL LIGHT

Thanks to the large openings that provide an enhanced sense of warmth and connection with the surrounding environment.

COMFORTABLE LIVING

A renewed design of perfect aesthetics and silent operation, with high security performance.

MINIMAL APPEARANCE

Design of new narrow overlapping profiles and low tracks, both in sliding and lift-and-slide systems.

High-performance constructions
In accordance with European standard EN 14351

Certified measurements for thermal transmittance coefficient Uf, air permeability, water tightness, wind load resistance, and operating forces, tested by the European testing laboratories ift Rosenheim & Giordano.

SPECIAL FEATURES

  • Flat tracks 25mm externally & 29mm internally, with the option of perimeter recess installation
  • & in the floor.
  • Large openings with the ability to construct widths over 6.5m and significant heights, with reinforcements that prevent deformation.
  • Energy-efficient glazing, double or triple, standard or safety glass.
  • Large handles for smooth operation & selectable locking positions wherever desired.
